| Place of Origin: | China |
|---|---|
| اسم العلامة التجارية: | SAFEGAS |
| إصدار الشهادات: | ATEX/EMC/IECEX |
| Model Number: | SKY3000 |
| Minimum Order Quantity: | 1 |
| الأسعار: | قابل للتفاوض |
| Packaging Details: | Aluminum Suitcase |
| Delivery Time: | 3 work days |
| Payment Terms: | T/T,Western Union |
| Supply Ability: | 1000 pieces per month |
| Gas type: | LEL, CO2, CO, H2S, O2, SO2 | Sampling method: | Pump suction |
|---|---|---|---|
| Measure range: | LEL 0-100%LEL, CO2 0-50000PPM, CO 0-500PPM, H2S 0-100PPM, O2 0-30%VOL, SO2 0-20PPM | Resolution: | 1%LEL(LEL), 100PPM(CO2), 1PPM(CO), 0.1PPM(H2S, SO2), 0.1%VOL(O2) |
| إصدار الشهادات: | CE,ATEX,IECEx,ISO | Language: | Chinese/English/ Russian /Customized |
| Alarm Mode: | Alarm by Buzzer , LED and vibration | Power: | With 3.7V rechargeable lithium battery |
| Working hour: | More than 15 hours(with pump on) | Data record: | Can store 100000 sets data |
| Single package size:: | 34cm*24cm*14cm | Single gross weight:: | 1.64kg |
| إبراز: | 6-gas portable detector with 15H battery,multi gas detector for LEL CO2 CO,H2S O2 SO2 gas detector portable,multi gas detector for LEL CO2 CO,H2S O2 SO2 gas detector portable |
||
| Feature | Specification |
|---|---|
| Sampling method | Pump suction |
| Gas type | LEL, CO2, CO, H2S, O2, SO2 |
| Measure range | LEL 0-100%LEL, CO2 0-50000PPM, CO 0-500PPM, H2S 0-100PPM, O2 0-30%VOL, SO2 0-20PPM |
| Resolution | 1%LEL(LEL), 100PPM(CO2), 1PPM(CO),0.1PPM(H2S, SO2), 0.1%VOL(O2) |
| Response time | ≤10 seconds |
| Precision | ≤±1%F.S |
| Language | English (Other languages can be customized) |
| Automatically test and calibrate after power-on | Including reset, maximum value (MAX), minimum value (MIN), STEL, TWA value |
| Unit | PPM and mg/m³ can be switched |
| Display | Monochrome graphics (160 x96), screen can be automatically flipped |
| Backlight | The backlight time can be manually set, and will be turned on automatically when an alarm is issued |
| Data record | Can store 100,000 sets data, the storage interval is adjustable from 5 to 3600 seconds, data can be exported |
| Alarm | 95dB buzzer (@30cm), vibration alarm and flashing red LED and alarm status indication on the screen, alarm latched; diagnostic alarm and battery undervoltage alarm, pump block alarm; man down alarm, with early warning and optional real-time remote Bluetooth notification function |
| Battery | 3.7V rechargeable lithium battery, battery capacity 2200mA |
| Working hours | More than 15 hours in continuous pumping mode |
| Charger | Travel charger with DC interface, charging time ≥ 4 hours |
| Explosion-proof grade | IECEX/ATEX(II IG Ex ia IIC T4 CNEX:Ex ia IIC T4 Ga |
| Certification (EU regulations) | 2004/108/EC(EMC) 1995/5/EC(Radio) 94/9/EC(ATEX) |
| Protection grade | IP67/IP68 |
| Working temperature | -20ºC~+50ºC |
| Humidity | 0~90%RH(no condensation) |
| Environmental pressure | 86~106Kpa |
| Size | 157*84.5*59.5mm (including back clip/water trap filter) (length * width * height) |
| Weight | 365g (including battery, belt clip and filter) |
| Bluetooth function (Optional) | Gas Concentration can be transmitted to the mobile phone or PC in real time |
